Beolab 5000
Beolab 5000
Verified
Knowledge 95%
Knowledge coverage
Derived from the facts and source material currently linked to this record.
- Core data80%
4 of 5 facts
- Verification100%
Verified
- Types & variants100%
2 of 2 areas
- Specifications100%
46 recorded
- Documents100%
1 available
- Images100%
3 linked
Images
External link only · product match verified
- Category
- Speakers
- Family
- Beolab
- Years
- 1990–1990
- Designer
- Gideon Lindinger-Loewy
- Official support
- Bang & Olufsen support
Current market (SE / DK)1
- UK · original_retail price£1,090
Generations & variants2
- BeoLab 5000Amplified panel loudspeaker
- BeoLab 5000 amplified panel loudspeaker1989-1990 panel-speaker generation
Type numbers5
- 6701220 (100-120-240) V
- 6702220 (100-120-240) V
- 6703220 (100-120-240) V
- 6704220 (100-120-240) V
- 6705220 (100-120-240) V
Key attributes46
- Amplifier frequency range+0 to -1 dB, 40–20,000 Hz
- Amplifier frequency range40–20,000 Hz (+0/-1 dB)
- Amplifier output powerApproximately 55 W
- Amplifier thd<0.1 at 55 W, 20–20,000 Hz
- Approximate output power55 W
- Cabinet principlebass reflex
- Cabinet principleBass reflex
- ConnectionPhono
- ConnectionPower Link
- ConnectionSpeaker Link
- Construction principleWall used as an active part of sound reproduction without causing the wall itself to vibrate
- Crossover frequency3500 Hz
- DesignerGideon Lindinger-Loewy
- DesignerGideon Lindinger-Low[e]y
- Dimensions45 × 101 × 8 cm (W × H × D)
- Dimensions45 x 101 x 8 cm
- Display amplifier configurationBeoLab designation indicates panel loudspeaker with amplifier and display; Beovox designation indicates version without amplifier
- Frequency range+4 to -8 dB, 60–20,000 Hz
- Frequency range60–20,000 Hz (+4/-8 dB)
- Harmonic distortion<0.1% at 55 W, 20–20,000 Hz
- Impedance8 ohms
- Long term maximum amplifier output90 W
- Long term maximum input power120 W
- Long term maximum output power90 W
- Maximum noise power60 W
- MountingWall mounting brackets supplied
- Mounting optionsNo other mounting solution offered
- Net volume14 litres
- Power at 94 db spl3.2 W
- Power consumption maximum130 W
- Power consumption standby2.6 W
- Power supply220 (100-120-240) V
- Product categoryamplified panel loudspeaker
- Product categoryAmplified panel loudspeaker
- Related system compatibilityBeosystem 6500, Beosystem 4500, Beosystem 3500, Beocenter 9500 and Beocenter 8500
- Sensitivity89 dB SPL at 1 W
- Speaker configurationtwo-way
- Speaker configurationTwo-way
- Standby functionAutomatic or manual ON-OFF
- System matchingBeoLab speakers were designed to match Beosystem 6500, 4500, 3500 and Beocenter 9500 and 8500
- Tweeter size1 in / 2.5 cm
- Tweeter size1 (2.5) inch (cm)
- Weight15 kg
- Woofer count2
- Woofer size5 in / 13 cm
- Woofer size5 (13) inches (cm)
Documents1
- Beolab 5000 MultilanguageOpen
